Description
Powerful Amplification and Yamaha Cinema DSP
The RX-V800RDS contains five internal power-amplifier channels, each rated at 100 watts into 8 ohms across the audio band. This provides amplification for the main left and right, centre and two surround speakers, with a dedicated line-level output for an active subwoofer.
Dolby Digital, DTS and Dolby Pro Logic decoding are built in, together with Yamaha’s Cinema DSP processing. A choice of 19 surround programmes and numerous variations allows the presentation to be tailored for films, music and television. Matrix 6.1 and DTS-ES processing are also available within the receiver’s five-channel amplified configuration.
Digital sources can be connected through four optical and two coaxial inputs. A six-channel analogue input is provided for compatible DVD-Audio players, SACD players or external multichannel decoders, bypassing the receiver’s internal digital processing.
The RX-V800RDS is also well equipped for conventional stereo listening. It includes a moving-magnet phono input for a compatible turntable, along with connections for CD, tuner, tape and other line-level sources. Bass, treble and Yamaha’s Bass Extension function allow the tonal balance to be adjusted when required.
Pre-amplifier outputs are provided for the main, centre and surround channels, allowing external power amplifiers to be added. A subwoofer output, switchable main-speaker connections and Yamaha’s Silent Cinema headphone processing add further flexibility.
The built-in FM/MW tuner includes RDS reception and storage for up to 40 preset stations.
Technical Specifications
Sources: Yamaha RX-V800RDS owner’s manual and HiFi Wiki.
- Type: Five-channel Natural Sound AV receiver
- Rated output: 100 watts per channel into 8 ohms, 20Hz–20kHz at 0.04% THD
- IEC output: 105 watts into 8 ohms at 1kHz
- Dynamic power: 125W/160W/195W/230W into 8/6/4/2 ohms
- Frequency response: 10Hz–100kHz, –3dB
- Damping factor: 80 or greater into 8 ohms
- Signal-to-noise ratio: 100dB from CD input; 81dB from MM phono input
- Surround decoding: Dolby Digital, DTS, Dolby Pro Logic, Matrix 6.1 and DTS-ES
- DSP processing: 19 Yamaha Cinema DSP programmes with multiple variations
- Digital inputs: Four optical and two coaxial
- Multichannel input: Six-channel analogue input
- Analogue inputs: MM phono, CD, tape and multiple audio/video sources
- Pre-amplifier outputs: Main, centre and surround channels
- Subwoofer output: Line-level output for an active subwoofer
- Video connections: Component, S-Video and composite video
- Radio tuner: FM/MW with RDS and 40-station preset memory
- Headphone facility: Silent Cinema surround processing
- Tone controls: Bass and treble, plus Bass Extension
- Remote control: Included
- Power consumption: Approximately 300 watts
- Standby consumption: Approximately 1.2 watts
- Dimensions: 435 × 171 × 432mm
- Weight: Approximately 15kg
Important Owner’s Notes
This is an early-2000s AV receiver and does not have HDMI connections, 4K/HDR video support, Bluetooth, network streaming or decoding for modern lossless formats such as Dolby TrueHD and DTS-HD Master Audio.
For use with a modern television or video source, the video signal can be connected directly to the display while compatible audio is sent separately to the receiver through an optical, coaxial or analogue connection.
Although Matrix 6.1 and DTS-ES processing are provided, the receiver contains five internal power-amplifier channels. It should not be mistaken for a modern seven-channel or Dolby Atmos receiver.
The built-in phono stage is intended for moving-magnet cartridges. A low-output moving-coil cartridge will require a suitable external phono stage or step-up device.
Why Buy From Us?
With over 40 years of experience in the hi-fi industry, we are well placed to assess equipment of this type. This Yamaha receiver was checked by Andrew before being offered for sale.
When you buy from us, you can expect:
- A three-month guarantee for additional reassurance.
- Inspection and operational checking before the item is listed.
- An accurate description of its condition, facilities and limitations.
- Professional packaging suitable for this substantial 15kg receiver.
- After-sales assistance available by phone or email.
- Competitive pricing with greater accountability than buying through eBay or an unverified private seller.
Summary
A powerful and well-equipped Yamaha AV receiver in A2 condition, combining five-channel amplification, Dolby Digital and DTS decoding, Cinema DSP processing, extensive digital connectivity and a useful MM phono input. It presents very well overall, includes a remote control and has been checked by Andrew.
This is a single-unit listing and includes our three-month guarantee. Please feel free to contact us with any questions before purchasing.
